100% New Honeywell 51199188-100 Module

Fast Delivery 100% Original Honeywell 51199188-100 Module

Introduction

Features  Type: XS831 Auxiliary Terminal Package For mounting onto the top and/or bottom of alreadyinstalled XF830A mixed I/O modules and the top ofalready-installed XFU830A and CPO-IO830 mixed I/Omodules in order to equip them with additional terminals. Two groups of four pairs of push-in terminals (A1B1,A2B2, … A8B8, each with a 499Ω resistor) for converting0…20 mA signals (max. load per resistor = 25 mA) into0…10 VDC signals, and one push-in ground terminal pergroup. See also Fig. 63 and Fig. 64.NOTE: The ground side of each of the eight incoming0…20 mA signals (A1B1, A2B2, … A8B8) mustbe connected to a ground terminal.

The LONWORKS Bus is a 78-kilobit serial link that uses transformer isolation so that the bus wiring does not have apolarity. I.e. it is not important which of the two LONWORKSBus terminals are connected to each wire of the twisted pair.The shield of the LONWORKS Bus must not be connected toany part of the controller. When connecting the LonWorksBus via the RJ45 interface, use an isolated plastic plug.The LONWORKS Bus can be wired in daisy chain, star, loop orany combination thereof as long as the max. wire lengthrequirements are met.

We focus on Honeywell DCS System Experion PKS ( C200 , C300 )  FSC

1. Control Processor, TK-PRR021, CC-PCNT01 51405046-175, TC-PRS021, TK-PRS021, CC-PFB801, CC-PFB401, 8C-PAIH51, 8C-PAOHA1

2. Fault Tolerant Ethernet Bridge ( FTEB ), TK-FTEB01 51309512-175, FC-TPSU-2430, FC-TSGAS-1624, FC-DCOM-232/485, FC-TSAI-1620M, FC-SAI-1620M, FC-SDI-1624

3. Controlnet Interface ( CNI ) , FC-TPSU-2430, FC-TSGAS-1624, FC-DCOM-232/485, FC-TSAI-1620M, FC-SAI-1620M, FC-SDI-1624

4. Redundancy Module ( RM ) TC-PRR021  51309288-225, TK-PRS021 51404305-375, TK-PRR021 51309288-275, TC-IXR061 96978373

5. IOLIM ( I/O Link Interface Module ) TC-IAH16I, TC-OAV081, TC-IXR061, TC-ODD321, TC-IAH161, TC-IXL061,  TK-PRR021

6. PM I/O Cards, TK-IOLI01 51403427-275, CC-TAIX01 51308363-175, CC-TAOX01 51308351-175, 8C-TDODA1 51307149-175, TK- IOLI01   51403427-275

7. FTA Cards, MC-TAIH02  51304453-150 UCN, MC-TDOY22 51204162-175 UCN, MC-TDIY22  51204160-175 UCN, MC-TAOY22 51204172-175 UNC, MC-PAIH03 51304754-150

8. FSC Module, 10024/H/F, 10020/1/2, 10018/E/1, 10101/2/1, 10004/H/F, 10105/2/1, 10201/2/1, 10001/R/1, 10006/2/1

9. UCN BOARD, 80363969-150  ( MC-PAOY22 ), 51309276-150, 51309355-001, 51304516-250, 51304754-150, MC-PAIH03, 51305430-100

You Might be Interested

Packaging & Shipping
1.All the goods will be tested before shipment.
2. Packing in professional anti-static bag.
3. We can ship to you by DHL/TNT/UPS/EMS/Fedex... Pls contact us directly and we will ship as your requirement.

About Us

Jak PLC for many years, is a professional engaged in large-scale system (distributed control system, programmable controller, redundant fault-tolerant control systems, robot control system, large servo control system is the central feeding system plastic molding auxiliary equipment and automation of whole plant planning) imported automation system such as spare parts, modules, sales and system integration of high-tech enterprises. The company is equipped with professional technicians to provide customers with better service.
