10020/1/2 Honeywell FSC CPU Module

FSC 10020/1/2 Module

Operation and maintenance performance

Safety Manager™ unifies critical process data and information with the processcontrol information, allowing single window access for operation andmaintenance. When connected to the Experion Fault Tolerant Ethernet (FTE)network via TÜV SIL3 approved Universal Safety Interfaces (USI), multipleSafety Managers are unified into a single safety system architecture.Extensive use of Ethernet for communication enables fast, safe and reliable dataexchange with Experion, enhancing operator and maintenance performance.Additionally, with inherent extensive system self-testing and diagnosticcapability, Safety Manager extends the system proof test interval, reducingoperational and maintenance costs.

PlantScape Integration

Safety Manager™ supports the integration of Safety Manager into PlantScape,which combines Honeywell’s safety controller with its equally reliable hybridcontrol system. The integration is realized through the Safety Manager UniversalSafety Interface module, which is placed in the control processor of the SafetyManager controller. This dedicated interface module makes Safety Manager anintegrated part of the PlantScape system architecture, which means that SafetyManager related information, can easily be exchanged between Safety Managerand PlantScape. This allows information to be shared and made available on thePlantScape server displays.

Safety Manager integrates the sequence-of-event (SOE) features as supportedby the Safety Manager controller into the PlantScape system. Safety Managersupports SOE for digital inputs and outputs, analog inputs and outputs, andmarker points. Each tag name that has been “SOE-enabled” is time-stamped bySafety Manager and reported to the PlantScape server, where it is incorporatedinto the standard PlantScape SOE table. Standard SOE displays are available toview the events as they are reported.Safety Manager integration into PlantScape requires PlantScape Release 300 orhigher.
