ABB 3BSE008544R1 AI820 Module

ABB AI820 ANALOG INPUT MODULE 3BSE008544R1

brand:
ABB
item no:
AI820 3BSE008544R1
payment:
T/T, Western Union, Credit Card
product origin:
Sweden
good stock:
11.0
shipping port:
Dammam, Saudi Arabia
lead time:
1-3 Working Days
condition:
Brand New And Original
warranty:
1 Year
certificate:
COO
description:
Analog Input Module
product type:
DCS 800XA

Product Details
FAQs

ABB AI820 3BSE008544R1 NEW IN STOCK

Information

The AI820 Analog Input Module has 4 differential, bipolar current/voltage inputs. Each channel can be either a voltage or current input. The current inputs can withstand an accidental maximum normal mode 30 V d.c. connection. To protect the current input circuit against dangerous input levels, that is, by accidentally connecting a 24 V source, the resistor rating of the 250W current sense resistors is about 5 Watts. This is intended only to temporarily protect one channel at a time.The module distributes the external transmitter supply to each channel. This adds a simple connection (with extended MTUs) to distribute the supply to external 2 wire transmitters. There is no current limiting on the transmitter power terminals.All 4 channels are isolated from the ModuleBus in one group. Power to the input stages is converted from the 24 V on the ModuleBus.
