ABB Bailey IMSET01 Infi-90 Module

ABB Bailey IMSET01 Sequence of Event Time Keeper Module

Description

The Distributed Sequence of Events (SOE) provides a fully integrated system approach to event monitoring, recording andreporting for the Symphony Enterprise Management and Control System. Digital input transitions are collected andtime-stamped at the time of occurrence. All input detectionmodules are time-synchronized, and coordinated through anexternal time input (e.g., satellite receiver system (SRS)). Thisevent input data is passed over the network to the INSOE01,Sequence of Events Server Node which is responsible for collecting and sorting event data coming from distributed Harmony control units (HCU). This stored event data is madeavailable to the human system interface for report generation.

The IMSET01 and IMSED01 modules perform two functions: The acquisition of the 16 digital inputs from the field. The synchronization of their internal clocks.The IMSET01 module receives the time information from thetime-sync link and keeps the internal clocks synchronized withthis time. The two modules are controlled by the controller,and communicate across the I/O expander bus. The controllerkeeps the IMSED01 modules synchronized by reading the timefrom the IMSET01 module and writing it to the IMSED01 modules with a broadcast messag
