ABB CI857K01 3BSE018144R1 Module

ABB CI857K01 3BSE018144R1 INSUM Ethernet Interface

Description

INSUM integration into AC 800M supports higher functionalityintegration, multidrop configurations, time distribution and timestamping in the switchgear, and utilizes standard Ethernettechnology for longer communication distances. The speed of thissolution is typically 500 ms for one closed loop (indication from onemotor until operation of another, assuming 250 ms cycle time incontrol execution).
AC 800M controllers access the INSUM functions through functionblocks in the INSUM Communication Library. The CI857 is powered
by the processor unit, via the CEX-Bus, and therefore does notrequire any additional external power source.

S800 information

S800 I/O provides distributed I/O on PROFIBUS and Advant Fieldbus 100(AF100). S800 I/O is also used as a communication link to some of ABB’s Drives.With the network definition PROFIBUS, it means the both versions;PROFIBUS-DP and PROFIBUS-DPV1.An I/O station can be configured over the Fieldbus. Typical parameters are signalrange, filter time, etc.The status of the modules are indicated by LEDs and also accessible over thefieldbus. Analog values are scaled 0-100% of the signal range. AI/AO modules arescanned every 4th I/O scan cycle. RTD/TC every 10th cycle.Values are transferred cyclically on the fieldbus limited by the fieldbus and thefieldbus master. The Fieldbus Communication Interface is scanning the I/O modulescyclically. The cycle time, 4-108 ms, is dependent on type and number of modules.
