ABB DSQC604 3HAC12928-1 Power Supply Module

ABB Robot Power Supply Power DSQC604 3HAC12928-1

Description

The brain of the S4 (Series 4) controller is located on the bottomof the swing gate. This brain consists of several computerboards all connected together by a back plane. In this chapterthe overall operation of the computer system will be explainedalong with a description of each individual board in the system.Also described in this chapter will be troubleshooting procedures.Diagram 2.1 shows the computer system and the boards in thecomputer, by a basic description of each board in thesystem.The S4 computer system consists of the following components:Main Computer. This board is the “BIG BOSS” of the system.The main computer performs all high level decision making. Itruns the application program and creates the motion “poses”that the system uses for to get through its program.Robot Computer. This board actually contains two computers,the Servo computer and the I/O computer. This board controlsthe Drive system and also controls all I/O communications.Memory Board. There are two different memory boards availablefor the S4 system. One has 4MB and the other has 6MB of RAM.The type of board used depends upon customer requirements.Battery Back-up. The computer system is battery backed bytwo 3.6 volt lithium batteries located below the computer boardsand plugged into the back plane. The robot computer will switchbetween the batteries to always have battery back-up protection.
