ABB NTAI06 BAILEY ANALOG INPUT TERMINATION

ABB NTAI06 Bailey infi 90 Universal 16 Analog Input Termination Unit

brand:
ABB
item no:
NTAI06
payment:
T/T, Western Union, Credit Card
product origin:
Sweden
good stock:
9.0
shipping port:
Dammam, Saudi Arabia
lead time:
1-3 Working Days
condition:
Brand New And Original
warranty:
1 Year
certificate:
COO
description:
Universal 16 Analog Input Termination Unit
product type:
Bailey INFI 90

Product Details
FAQs

ABB BAILEY INFI 90 NTAI06 MODULE

Input Circuit Description

When an input signal is present at the proper voltage level, azener diode conducts (turns on) to cause current flow throughan optocoupler. Configurable jumpers (on IMDSI22) or fixedresistors (on IMDSI13, IMDSI14 modules) select the turn-onthreshold and input voltage.

The optocoupler output causes a comparator output to go low.This lights a corresponding status LED on the module frontpanel to indicate an energized input. The I/O expander businterface transmits a logic one to the controller on the I/Oexpander bus. When no input signal is present, no currentflows through the optocoupler. The front panel LED does notlight and the DSI module transmits a logic zero on the I/Oexpander bus
