Allen Bradley 1746-A10 Rack SLC 500

Allen Bradley 1746-A10 10 Slot Rack SLC 500

brand:
Allen Bradley
item no:
1746-A10
payment:
T/T, West Union, Credit Card
product origin:
USA
shipping port:
Saudi Arabia
lead time:
1-3 Working Days
condition:
Brand New And Original
warranty:
12 Months
certificate:
COO
description:
Rack
product type:
SLC 500

Product Details
FAQs

Rockwell Allen Bradley 1746-A10 Rack SLC 500 Module

About 1746-A10

The 1746-A10 is an Allen-Bradley manufactured chassis used with the SLC 500 Modular Programmable Logic Controllers (PLC) platform.

This hardware hosts the electronic circuitry and interconnection slots to distribute the backplane power to the attached modules. It can accommodate up to Ten (10) SLC 500 modules excluding the Power Supply. The Power Supply has a separate attachment slot located at the leftmost part of the hardware. Only SLC 500 Power supplies may only be used with this hardware.
SLC 500 Chassis such as the 1746-A10 allows connection or expansion of chassis with the use of 1746-C9 and 1746-C7 expansion cable. Up to Three (3) SLC chassis may be connected which sums up to 30 SLC 500 modules. Each chassis shall have an individual Power supply.

The chassis must be properly configured in the programming software with the use of the RSLogix 500 software. It is important to match the part number in the software to the actual physical hardware to qualify the controller configuration.

SLC 500 System Overview

The Allen-Bradley SLC 500 is a small chassis-based family of programmable controllers,discrete, analog, and specialty I/O, and peripheral devices. The SLC 500 family deliverspower and flexibility with a wide range of communication configurations, features, andmemory options. The RSLogix 500 ladder logic programming package provides flexibleeditors, point-and-click I/O configuration, and a powerful database editor, as well asdiagnostic and troubleshooting tools to help you save project development time andmaximize productivity.

Allen Bradley 1746-A10
