Allen Bradley 1756-L55M13 ControlLogix Processor

ALLEN BRADLEY 1756-L55M13 EXPANSION

Description

The Allen-Bradley 1756-L55M13 is a Series A ControlLogix 5555 controller. While this particular controller does not have a nonvolatile memory available, it does have a 1.5 Mbytes data and logic memory and 208 kbytes I/O memory available. The 1756-L55M13 controller also has a weight of 0.35 g or 12.5 oz. It does not have an enclosure type rating since it is an open-style controller.

As part of the ControlLogix system, it is used in conjunction with the RSLogix 5000 software and located inside a ControlLogix 1756 chassis. It also has the capacity to support the following communication options: DeviceNet, ControlNet, Ethernet/IP, Universal Remote I/O serial, Data Highway Plus, Modbus via ladder routine, SynchLink, and DH-485.

The 1756-L55M13 has backplane currents of 0.014A at 24V DC and 1.23 A at 5.1V DC. Its thermal dissipation is 19.1 BTU/hr, while its power dissipation is 5.6W. It has a basic insulation type and a continuous isolation voltage of 30V and has also been tested to withstand 707V DC for 60s. The conducted RF immunity of the 1756-L55M13 controller is 10V rms with 1 kHz sine-wave 80%AM from 150 kHz to 80 MHz.

The storage temperature of the controller is between -40 to 85 Degrees Celsius and the operating temperature is between 0 to 60 Degrees Celsius. Relative humidity, which is noncondensing, is from 5% to 95%. It has a vibration of 2 g at 10 to 500 Hz, an operating shock of 30 g, and a non-operating shock of 50 g.

This controller has batteries that can be replaced but only if needed and is only compatible with the 1756-BA1 lithium battery. It can only be connected with either the 1756-CP3 or 1747-CP3 programming cable. The 1756-L55M13 controller can be used in a redundant controller system but it needs to be located in the same ControlNet network.

FAQ:

1.Is the part new?
   Yes, 100% Original brand new

2.How is the package?
   Original factory seal packed

3.What is the lead time?
   In stock: 1-3 working days

4.What is the MOQ:
   1pcs

5.What is the payment term:
   TT and Western Union, other negotiable

6.Where the item ship from?
   Dammam

7.What is the warranty time?
   One year

8. How to delivery the PLC Parts?
   Kindly tell us your address,we check best cost for you
   Or you can use your own courier account or agent, DHL, FEDEX, UPS etc are available.
