Allen Bradley 1756-L73S Processor ControlLogix

Allen-Bradley 1756-L73S Controller

Description

The Allen-Bradley 1756-L73S is a GuardLogix 5570 controller that is a part of the Logix5000 family of controllers. It is a ControlLogix controller with safety control features. It is a dual processor solution that must be used with a 1756-L7SP safety module to meet the SIL 3 or Cat. 4/PLe standards. The safety partner controller is automatically configured providing major benefits to a single project. It has greater processing capabilities and speed for motion and high-performance logic. It has a USB port for communication. It can support up to 500 controller connections.

The 1756-L73S controller has 8MB of user memory, 4MB of safety memory, and 0.98MB of I/O memory. It can support 128,000 digital I/O and 4000 analog I/O. It draws a current of 5mA at 1.2V DC and of 800mA at 5.1V DC. Its power dissipation is 2.5W and its thermal dissipation is 8.5 BTU/hr. It weighs 0.55lbs and has an isolation voltage of 30V (continuous) for basic insulation. It can be installed in any slot of a ControlLogix 1756 chassis and multiple controllers can also be installed in the same chassis. For safe communication, it uses ControlNet, DeviceNet, or EtherNet/IP networks. It is programmed using RSLogix 5000 software with relay ladder logic for safety tasks.

The 1756-L73S controller can control or monitor I/O over the backplane or through the I/O links. For controller diagnostics, it has a front display that provides runtime information. It uses energy storage modules, which means that lithium batteries are not needed. A 1 GB (1784-SD1) Secure Digital card comes pre-installed as an optional non-volatile storage which can be expanded up to 2 GB (1784-SD2).

FAQ:

1.Is the part new?
   Yes, 100% Original brand new

2.How is the package?
   Original factory seal packed

3.What is the lead time?
   In stock: 1-3 working days

4.What is the MOQ:
   1pcs

5.What is the payment term:
   TT and Western Union, other negotiable

6.Where the item ship from?
   Dammam

7.What is the warranty time?
   One year

8. How to delivery the PLC Parts?
   Kindly tell us your address,we check best cost for you
   Or you can use your own courier account or agent, DHL, FEDEX, UPS etc are available.
