Allen Bradley 1756-OW16I Contact Controllogix PLC Module

New Sealed AB 1756-OW16I ControlLogix 16 Point Digital Module 1756OW16I AC (10…240V) DC (5…125V)

brand:
Allen Bradley
item no:
AB 1756-OW16I
payment:
TT Or Western Union
product origin:
USA
shipping port:
Dammam
lead time:
1-3 Working Days
condition:
Original New
warranty:
12 Months
description:
ControlLogix Contact Module
product type:
1756 Solated Relay Output Module
system:
ControlLogix

Product Details
FAQs

New Factory Seal Allen-Bradley 1756-OW16I ControlLogix Digital Relay Module

1756-OW16I Product Info:

Allen Bradley 1756-OW16 is one of the 1756 output Module.

The 1756-OW16I ControlLogix AC/DC Isolated Contact Module by Allen-Bradley is a ControlLogix contact module with 16 Normally-Open (NO) individually-isolated outputs with a pilot duty rating of C300/R150. The module has a DC and AC operational voltage range of 5 to 125 Volts DC and 10 to 240 Volts AC, respectively. The 1756-OW16I’s output delay time for both ON to OFF and OFF to ON is 10 milliseconds and it draws a backplane current of 150mA at both 5.1 Volts and 24 Volts DC and it has a total backplane power of 4.4 Watts. It has a thermal dissipation of 15.35 BTU/hour and dissipates 4.5 Watts at 60 degrees Celsius. Each outpoint can accommodate a minimum current load of 10mA and a current leakage of 1.5 mA per point.

Allen Bradley1756-OW16I Technical Specificiation:

Part Number/Catalog No.	1756-OW16I
Manufacturer	Rockwell Automation
Outputs	240V AC 50/60 Hz
Operating voltage	10-265 Volts AC, 5-150 Volts DC
Output Current	2, 0.5, 0.25 Amps
Maximum Output Delay Time	10 milliseconds
Contact Output	13 N.O.
Power Dissipation (Max)	4.5 Watts at 60 Celsius
Isolation Voltage	50 Volts Continuous
Enclosure	None
Backplane Current at 5/24 Volts	150 milliamps

Frequently asked questionsfor 1756-OW16I:

1: What is this module’s power dissipation?

The 1756-OW16I has a power dissipation of around 4.5 Watts at a 60 degree Celsius temperature.
2: Can this module be purchased with a warranty?

Yes, the 1756-OW16I comes with a free one-year warranty from DO Supply, Inc.
3: What is this module’s operating voltage?

The 1756-OW16I can operate on 10 to 265 Volts of AC power or on 5 to 150 Volts of DC power.
