Allen Bradley 1756-PA75 Power Supply Module

Sealed Allen Bradley 1756-PA75 /B ControlLogix AC Power Supply New Saled

About 1756-PA75:

The Allen-Bradley 1756-PA75 Standard AC Power Supply comes with 120 to 240 Volts AC nominal input voltage.

AB 1756-PA75power supply is part of the ControlLogix power supply series and it provides built-in overcurrent protection which is user-supplied at a maximum rate of 15 A. The 1756-PA75 power supply also has a type of reinforced insulation tested at 3,500 Volts DC for 60 seconds. The maximum transformer load of this power supply is 100VA. The voltage isolation of the 1756-PA75 is 250 Volts continuous. The 1756-PA75 has a power consumption of 25 Watts at 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit). This power supply has a power dissipation of 85.3 BTU/hour and a maximum inrush current of 20 A. The input frequency range of the 1756-PA75 is 47 to 63 Hertz. The power supply’s maximum input power is 100VA/100 Watts and the maximum output power is 75 W at 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit).

Technical Specifications For Allen Bradley 1756-PA75:

1756 ControlLogix I/O Specifications:

AC Digital Catalog Numbers :1756-IA8D, 1756-IA16, 1756-IA16K, 1756-IA16I, 1756-IA16IK, 1756-IA32, 1756-IA32K,1756-IM16I, 1756-IM16IK, 1756-IN16, 1756-OA8, 1756-OA8D, 1756-OA8E, 1756-OA16,1756-OA16K, 1756-OA16I, 1756-OA16IK, 1756-ON8DC

 Digital Catalog Numbers: 1756-IB16, 1756-IB16K, 1756-IB16D, 1756-IB16DK, 1756-IB16I, 1756-IB16IK, 1756-IB16IF,1756-IB16IFK, 1756-IB16ISOE, 1756-IB16ISOEK, 1756-IB32, 1756-IB32K, 1756-IC16, 1756-IG16,1756-IH16I, 1756-IH16ISOE, 1756-IV16, 1756-IV16K, 1756-IV32, 1756-IV32K,1756-OB8, 1756-OB8EI, 1756-OB8I, 1756-OB16D, 1756-OB16DK, 1756-OB16E, 1756-OB16EK,1756-OB16I, 1756-OB16IEF, 1756-OB16IEFK, 1756-OB16IEFS, 1756-OB16IS, 1756-OB32,1756-OB32K, 1756-OC8, 1756-OG16, 1756-OH8I, 1756-OV16E, 1756-OV32E
