Allen Bradley 1762-L24BXB Micrologix 1200

1762-L24BXB Allen Bradley MicroLogix 1200 14 Input 24VDC 5 Relays

Description

The Allen-Bradley 1762-L24BXB is a 24-point controller module. It belongs to the 1762 series. The input power of this module is 24 Volts DC and it has 14 inputs and 10 outputs. The inputs consist of 10 inputs of 24 Volts DC power and 4 inputs of fast 24 Volts DC power. The outputs of this module consist of 5 relays, 4 of 24 Volts DC FET power, and 1 of high-speed 24 Volts DC FET power. This equipment is designed for use in an industrial enclosure which reduces the effects of electrical interference and environmental exposure. Install this device as far as possible from load lines, power lines, relays, AC motor drives, and other electrical noise.

The 1762-L24BXB has different specifications than other controller modules. Its heat dissipation is 17 Watts and its power supply inrush current is 15 Amps for 20 milliseconds at 24 Volts DC. The power supply usage of the 1762-L24BXB is 27 Watts. The output circuit type of this module can be either Relay or FET type. The input circuit type is 24 Volts DC sink or source. This module has no sensor power output. The input specifications of the 1762-L24BXB are same as those of other controllers in the 1762 series. The minimum output load current is 10 mA, the common current per group is 7.5 Amps, and the power supply output of the 1762-L24BXB is 400 mA at 5 Volts DC and 350 mA at 24 Volts DC. Refer to the MicroLogix Controllers Reference Manual for further details.
