Allen Bradley 1769-ECR Right End Cap Module

Fast Delivery Allen Bradley 1769-ECR Module

Introduction

The Allen-Bradley 1769-ECR is a right end cap or terminator that terminates the end of the communication bus of a 1769 controller. It has a maximum bus current draw of 5 mA at 5V DC. It comes with an operating altitude of 6562 feet and an approximate shipping weight of 0.286 lbs. It has an open-type enclosure to ensure safety and it can adapt to certain conditions to reduce the risk of fire and injury. To meet health and safety requirements, the 1769-ECR should be installed with IP54 protection when applied in zone 2 environments because it has no tolerance for sunlight and other UV radiation sources.

The 1769-ECR has an operating temperature of 32 - 140 °F tested in cold, dry heat, and thermal shock environments. It has a non-operating temperature of -40 - 185 °F tested unpackaged during cold, dry heat, and thermal shock. The also 1769-ECR has a 5 - 95% noncondensing relative humidity and its vibration reaches 5 g at 10 - 500 Hz tested during operating. It has an operating shock is 20 g on a DIN rail mount and 30 g on a panel mount. Its non-operating shock is 30 g on a DIN rail and 40 g on a Panel mount.

Allen Bradley Main Products:

1. SLC500:1747/1746 series
2.MicroLogix: 1761/1763/1762/1766/1764 series
3.CompactLogix: 1769/1768 series
4. The ControlLogix: 1756/1794/1760/1788 series
5. PLC-5:1771/1785 series
6.2711,2711P PanelView man-machine interface, touch screen, operation panel
7.22A,22B, 20 small frequency converter,150 soft starter
8. ProSoft: MVI69 / PS69 / MVI56 / MVI94 / MVI71 / MVI46/3150 9. ICS TRIPLEX: T8431 / T8461 / T3401 / T8310

Our Advantage

*Please let us know if you have any spare parts, spare parts, we can give you further assistance, we await your inquiry.

FAQ:
1.Is the part new?
   Yes, 100% Original brand new
2.How is the package?
   Original factory seal packed
3.What is the lead time?
   In stock: 1-3 working days
4.What is the MOQ:
   1pcs
5.What is the payment term:
   TT and Western Union, other negotiable
6.Where the item ship from?
   Dammam
7.What is the warranty time?
   One year

8. How to delivery the PLC Parts?
   Kindly tell us your address,we check best cost for you
   Or you can use your own courier account or agent, DHL, FEDEX, UPS etc are available.
