Allen Bradley 1769-IQ32 Compact I/O 32 PT Input Module

Allen Bradley 1769-IQ32 CompactLogix Input Module

brand:
Allen Bradley
item no:
1769-IQ32
payment:
T/T, Western Union, Credit Card
product origin:
USA
good stock:
4.0
shipping port:
Dammam
lead time:
1-3 Days
condition:
Brand New And Original
warranty:
12 Months
certificate:
COO
description:
DC Input Module
product type:
CompactLogix

Product Details
FAQs

Allen-Bradley1769-IQ32 Compact DC I/O Module

About 1769-IQ32

The 1769-IQ32 digital compact input module by Allen-Bradley is a digital input module in the CompactLogix I/O series with thirty-two 24 Volts DC current sinking and sourcing inputs (8 groups per point) with a functional input voltage range between 10 and 30 Volts DC at 30 degrees Celsius, and 10 to 26.4 Volts DC at 60 degrees Celsius. It has 8 milliseconds ON and OFF signal delay time and a draw current of 170mA. It has a maximum inrush current of 250mA and an input impedance of 5.2kW at 24 Volts DC and 6.1kW at 30 Volts DC. It dissipates heat at 15.68 BTU/Hour and a 4.6W equivalence. It has an OFF-state input voltage of 5 Volts DC at a current of 1.5mA, and an ON voltage of 10 Volts DC at 2.0mA.

The 1769-IQ32 has a reinforced insulation circuit with an isolation voltage of 75 Volts DC tested at 1697 Volts DC for 1 seconds between the input point and BUS, and between group-to-group (4 groups in total). It has a slot width of 1.5 inches and is installed on either a panel mount or a DIN rail using the specialized 6 lb x inches terminal screws. It has an open-style enclosure rating, is shipped with a replacement door, and has a Type 1+ IEC input compatibility. The 1769-IQ32 is c-UL and CE certified for safe operation in the US, Canada, and Europe. It has a functional temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) at 5 to 95% relative humidity and it will function without de-rating at a maximum altitude of 2000 meters (6561 feet). The 1769-IQ32 weighs 440g (0.97 pounds), and has shipping dimensions of 118 x 52.5 x 87 millimeters (4.65 x 2.07 x 3.43 inches).
