Allen-Bradley 1769sc-IF4IH Module

100% Rockwell Allen-Bradley 1769sc-IF4IH Module In Stock

Introduction

The 1769SC-IF4IH is an compass partner module that is compatible for use with the CompactLogix and MicroLogix 1500 Programmable Automation Controllers (PAC). This module is manufactured by Spectrum Controls for the 1769 Compact I/O system.
The 1769SC-IF4IH is an analog input module with Highway Addressable Remote Transducer (HART) capability. This module accepts 0-20 mA and 4-20 mA Current signals plus HART capability. It is also compatible with 0-5VDC, 1-5VDC, 0-10VDC and +/- 10VDC input voltages. This module has an analog input resolution of 16-Bits and support HART dynamic variables of PV, SV, TV and FV. It has Five (5) filter frequencies, selectable by the user, individually for each channel. Available channel frequencies are 28.5 Hz, 50 Hz, 60 Hz, 300 Hz, and 360 Hz. This module has an update time of 18 to 488 ms for all channels and Six (6) second update time for HART.
The 1769SC-IF4IH has an internal analog to digital converter. Converted data is saved in Integer data format which can be further defined as engineering units, Scaled for PID, Percent of Full-scale and Raw / proportional data.
This module is a single slot module that may be installed to any adjacent module of the CompactLogix chassis. It has compatible levers to allow connection to adjacent pins to establish bus connection. It is configured using RSLogix 5000 or Studio 5000 Logix Designer programming software, depending on the firmware version of the CompactLogix controller.
The 1769SC-IF4IH has a module accuracy of ±0.2% of range voltage and ±0.35% of range current. It is factory calibrated and carries certifications from UL/cUL Listed ANSI ISA 12.12.01 (Class I, Div 2, Groups ABCD), CE.
