Allen Bradley 2711C-T4T PanelView C400 Terminal

Allen Bradley 2711C-T4T PanelView C400 Terminal NEW

Description

The 2711C-T4T has insulation rating tested at 500 Volts for 60 seconds. The embedded touchscreen has an actuation rating of more than 1 million presses. The 2711C-T4T terminal comes with a 4.3-inch display. It has an embedded web browser which can be accessed through an Ethernet connection. The C400 terminal is compatible with most operating systems, making interfacing with a PC or remote device simple. The preferred compatible controllers are the Micro800 and SLC controllers. The on-terminal programming software reduces the start-up and service time by removing the need to install the software on a personal computer.

The 2711C-T4T terminal uses input voltage, 24 Volts DC normal and an average power consumption of 5 Watts maximum. Disconnect all of the electrical power from the panel before making the panel cutout. This C400 PanelView terminal supports Firefox 3.0 and Internet Explorer 7/8 for easy operation with a PC. It can also alert users with alarm messages by using different variables. The users can change the language of the terminal for diagnostic messages and configuration. Weighing approximately 0.76 pounds with a display size of 3.74 x 2.12 inches, the PanelView Component C400 has RS-232 (DH-485), RS-232 (DF1), RS-485, and Ethernet as the communication ports. Users can view the results on the terminal without downloading the application thanks to an add-on feature that enables login credentials every time they start the terminal. The 2711C-T4T has a control and visualization option for simple applications which use serial or Ethernet communication. The display comes with programming software that is accessible over a web-browser via a USB or Ethernet connection. The 2711C-T4T allows users to design their applications and alter terminal settings while simultaneously viewing the results on the connected terminal. Other 2711C-T4T features include secured programming access, alarm messages and history, unicode language switching, and recipe operations. Additionally, integrated mounting clamps and quick-lever clips make the installation process and maintenance of the 2711C-T4T easy.
