Bently Nevada 3500/60-05-01 Temperature Monitors

Bently Nevada 3500/60-05-01 New In Stock

Description

The 3500/60 & 61 modules provide six channels of temperature monitoring andaccept both Resistance Temperature Detector (RTD) and Thermocouple (TC)temperature inputs. The modules condition these inputs and compare themagainst user-programmable alarm setpoints. The 3500/60 and 3500/61 provideidentical functionality except that the 3500/61 provides recorder outputs foreach of its six channels while the 3500/60 does not.The user programs the modules to perform either RTD or TC temperaturemeasurements using the 3500 Rack Configuration Software. Different I/Omodules are available in RTD/TC non-isolated or TC isolated versions. The usercan configure the RTD/TC non-isolated version to accept either TC or RTD, or amixture of TC and RTD inputs. The TC isolated version provides 250 Vdc ofchannel-to-channel isolation to protect against external interference.When used in a Triple Modular Redundant (TMR) configuration, temperaturemonitors must be installed adjacent to each other in groups of three. When usedin this configuration, the system employs two types of voting to ensure accurateoperation and to avoid single-point failures.

The primary purpose of the 3500/45 monitor is to provide:1. Machinery protection by continuously comparing monitored parametersagainst configured alarm setpoints to drive alarms.2. Essential machine information for both operations and maintenancepersonnel.Each channel, depending on configuration, typically conditions its input signalinto various parameters called “proportional values”. Alert setpoints can beconfigured for each active proportional value and Danger setpoints can beconfigured for any two of the active proportional values.

Ordering Information

The 3500/33 requires 3500 Rack Configuration software, version 3.3 or later

The 3500/33 requires 3500 Data Acquisition software, version 2.40 or later

The 3500/33 requires 3500 Data Display software, version 1.40 or later

When used with a 3500/93 LCD Display module, the 3500/93 will require firmware revision P or later.

When used with a 3500/94 VGA Display module, the 3500/94 will require firmware revision C or later
