Brand New Allen Bradley PLC 1715-TASIF16 In Stock

The 1715-TASIF16 is a redundant I/O termination assembly module. The module fits into a small installation area. The device has an open enclosure with the IP20 rating. The IP20 rating indicates that the device is not water-resistant. The device should be kept inside a shielded bag when it is not in use. The power dissipation in this type of I/O termination assembly is 4 Watts and the field loop dissipation is a maximum of 0.075 Watts per field loop. The 1715-IF16 module is also supported by this module. This 16-channel module has basic insulation from I/O ports to the backplane but no insulation is present in between the individual I/O ports. The 1715-TASIF16 is enabled with an RFI suppression device. The connecting cables used in this module are made of stranded copper wire and it weighs only 133 grams.

The 1715-TASIF16 module can be mounted using a DIN rail. It can withstand a maximum temperature of 158 degrees Fahrenheit during its normal operation. A 95% humid environment is the maximum non-condensing humidity level for this module. The terminal assembly module is fitted and tested at 500 Volts AC for 60 seconds. The temperature required to run this assembly ranges from -13 degrees Celsius to 158 degrees Celsius. The 1715-TASIF16 has a screw torque rating of 0.5 N-m. It has an input resolution of 0.0039 milliamps/cnt. This terminal assembly module has been certified with the UL, CE, C-Tick, Ex, and KC standards. These certifications ensure that the industrial safety and environmental requirements in different regions are all met. It also meets multiple industrial emission standards. For communication purposes, it comes with a shielded RJ45 connector. The device should be properly grounded before installation. The airflow should be enhanced with good ventilation and the environment should be free from corrosive materials, dirt, and oil.
