Emerson Kj4001x1-Ba2, 2-Wide Carrier

KJ4001X1-BA2 by EMERSON

Terminology

Equipment modules coordinate the operation of control modules and otherequipment modules that work together to control related equipment. The algorithmfor the containing equipment module manages the operation of the containedmodules.

Control strategies in the DeltaV system are configured in modules. A module, whichis the smallest logical control entity in the system, contains algorithms, conditions,alarms, displays, historical information, and other characteristics that define theprocess equipment. Algorithms are the logical steps that define how the modulebehaves. The DeltaV system provides control, equipment, and unit modules.Generally, a control module contains one uniquely tagged control entity, such as acontrol loop or motor, with its associated logic. Defining a module around a singlefield device and its related control logic makes it easy to create, download, operate,debug, and take a single module out of service without affecting other modules.

System Identifier

The System Identifier, shipped in the License Pack, is a connector that plugs into theparallel printer port or Universal Serial Bus (USB) on the ProfessionalPLUSworkstation. It gives each DeltaV system a unique identification that allows you todownload changes to the system. Install the System Identifier on theProfessionalPLUS workstation before you power up your system. DeltaV systems maybe engineered and configured using a Development System Identifier prior to goingonline. DeltaV systems used for training or simulation may use a Multi-Node SimulateSystem Identifier. Development and Multi-Node Simulate System Identifiers cannotbe used for online, running systems. Only a User System Identifier can be used withan online system. Refer to the Knowledge Base for information on converting asystem based on a Development or Multi-Node System Identifier to one based on aUser System Identifier.
