GE Bently Nevada 136188-02 Ethernet/RS485 Modbus I/O Module For 3500/92

In Stock Bently Nevada 3500/92 136188-02 Ethernet/RS485 Modbus I/O Module

brand:
Bently Nevada
item no:
Bently Nevada 3500/92 136188-02
payment:
TT,Western Union
product origin:
USA
good stock:
30.0
shipping port:
Dammam
lead time:
1-3 Days
condition:
Original New
warranty:
1 Year
certificate:
Co,Coo
description:
136188-02
product type:
3500/92 136188-02 I/O Module
system:
Bently Nevada 3500 Monitor System

Product Details
FAQs

Bently 136188-02 Ethernet/RS485 Modbus I/O Module for 3500/92 In Stock

Overview

The 3500/92 Communication Gateway module providesextensive communication capabilities of all rack monitoredvalues and statuses for integration with process control andother automation systems using both Ethernet TCP/IP andserial (RS232/RS422/RS485) communications capabilities. Italso permits Ethernet communications with 3500 RackConfiguration Software and Data Acquisition Software.

The Ethernet connection to the 3500/92 is an RJ45 connectionfor 10BASE-T star configuration Ethernet networks.The 3500/92 supports the communication interfaces,communication protocols, and other features from theoriginal 3500/90 with the exception of the primary valueModbus registers. The 3500/92 now has a ConfigurableModbus Register Utility, which can provide the samefunctionality originally addressed by the primary valueModbus registers.

Specification

Part No.	3500/92
I/O Module	136188-02
Other Modules	136180-01, 125736-01, 133323-01, 136188-01
Inputs Power Consumption	5.0 watts typical with ModbusRS232/ RS422 I/O Module 5.6 watts typical with Modbus RS485 I/O Module
Outputs OK LED:	Indicates when the 3500/92 is operating properly.
Outputs TX/RX LED:	Indicates when the 3500/92 is communicating with other modules in the 3500 rack
BNC Host Protocol	Communication with 3500 Configuration Software and 3500 Data Acquisition and Display Software over Ethernet TCP/IP
Modbus	Based on AEG Modicon PIMBUS-300 Reference Manual.Uses Remote Terminal Unit (RTU) transmission mode.
