GE Bently Nevada 3500/33 16-Channel Relay Module

GE Bently Nevada 3500/33 16-Channel Relay Module in Stock

brand:
Bently Nevada
item no:
Bently Nevada 3500/33
payment:
TT,Western Union
product origin:
USA
good stock:
20.0
shipping port:
Dammam
lead time:
1-3 Days
condition:
Original New
warranty:
1 Year
certificate:
Co,Coo
product type:
Relay Module
system:
Bently Nevada 3500

Product Details
FAQs

Original New GE Bently Nevada 3500/33 16-Channel Relay Module in Stock

Overview

The 16-Channel Relay Module is a full-height module that provides 16 relayoutputs. Any number of 16-Channel Relay Modules can be placed in any of theslots to the right of the Rack Interface Module. Each output of the 16-ChannelRelay Module can be independently programmed to perform needed votinglogic.Each relay utilized on the 16-Channel Relay Module includes "Alarm Drive Logic". Programming for the Alarm Drive Logic uses AND and OR logic, and can usealarming inputs (Alert and Danger statuses), Not- OK, or individual PPLs fromany monitor channel or any combination of monitor channels in the rack. Usersprogram this Alarm Drive using the 3500 Rack Configuration Software to meetthe specific needs of the application

Ordering Considerations

The 3500/33 requires 3500 RackConfiguration software, version 3.3 or later

The 3500/33 requires 3500 Data Acquisitionsoftware, version 2.40 or later• The 3500/33 requires 3500 Data Displaysoftware, version 1.40 or later

When used with a 3500/93 LCD Displaymodule, the 3500/93 will require firmwarerevision P or later.• When used with a 3500/94 VGA Displaymodule, the 3500/94 will require firmwarerevision C or later

Specifications

Part No.	3500/33
Power Consumption	5.8 watts typical.
Relays Type	Single-pole, double-throw (SPDT) relays
Physical Main Module Dimensions (Height x width x depth)	241 mm x 24.4 mm x 242 mm (9.50 in. x 0.96 in. x 9.52 in.)
Physical Main Module Weight	0.7 kg (1.6 lb.)
I/O Module Dimensions	241 mm x 24.4 mm x 99.1 mm (9.50 in. x 0.96 in. x 3.90 in.).
I/O Module Weight	0.4 kg (1.0 lb.)
