GE Fanuc IC200ALG262 Module

100% new and original PLC IC200ALG262

Description

IC200ALG262 is a 15 Bit Differential Current Module with eight channels from GE Versamax. This analog input module offers an interface to eight analog current inputs that receive power from the backplane power supply. This means no external power source is necessary for module operation. However, power for the user’s transceivers is required from an external source.

The IC200ALG262 has a single group of eight differential input channels with 15-bit converter resolution. The CPU or NIU performs the intelligent processing for this unit as the module provides eight words of analog input data. This unit reports a loss of power fault for field side circuits and open wire faults for every channel but only in 4-20mA mode. A jumper on the carrier terminal can be used to configure this range or the 0-20mA input range as needed, or the lack of a jumper cable will allow the module to use the 4-20mA range. Additionally, LED lights indicate power and proper functioning.

When first installing the IC200ALG262 module, carefully inspect all parts for damage. Do not use damaged parts as this may affect overall functioning. Analog channel connections should be created with shielded twisted pair cable with the cable grounded at the source device. However, if unable to ground at the source, then grounding at the I/O module is appropriate and can be done using the auxiliary I/O terminal. If this option is used, shield connections can be made on an auxiliary I/O terminal connected to the I/O carrier. If additional connections are required, an auxiliary I/O terminal strip can be utilized.
