GE Fanuc IC693MDL340 Module

GE Fanuc IC693MDL340 Output Module

brand:
GE Fanuc
item no:
IC200ALG430
payment:
T/T, Western Union,Credit Card
product origin:
USA
good stock:
5.0
shipping port:
Dammam, Saudi Arabia
lead time:
1-3 Working Days
condition:
Brand New
warranty:
One Year
certificate:
COO
description:
Output Module
product type:
Series 90-30

Product Details
FAQs

GE Fanuc IC693MDL340 Series 90-30Module 120 VAC 0.5 A 16-Point

Description

The IC693MDL340 is a 120 volt, 0.5 Amp AC Output Module of the Series 90-30 manufactured by GE Fanuc. It provides 16 output points in two isolated groups with eight points in each. Each of these groups has a separate common associated with it (the two commons are not integrated inside the IC693MDL340), allowing each group to be used with independent AC supply phases. Alternatively, it is also possible to power both commons with the same supply. Each group has a 3-ampere fuse for protection, as well as an RC snubber for each output to guard them against transient electrical noise from the power line. This module also has an output voltage range of 85 to 132 volts AC, 50/60 Hz, and an output current of 0.5 amperes maximum per point. The maximum per group is 3 amps.
