GE Fanuc IC695PSD140 RX3i Multi Function

GE Fanuc IC695PSD140 Power Supply

Description

GE Fanuc manufactures the IC695PSD140 module as a power supply unit and a member of the RX3i PACSystems series. This module is a multi-purpose power supply and it can operate in the redundancy applications as well as in load-sharing applications, making it a multipurpose unit. The IC695PSD140 power supply features 3 different output points rated at 5.1 Volts DC, a relay output rated 24 Volts DC, and an output voltage of 3.3 Volts DC for internal use. The 3 outputs are well-matched and usable with the RX3i modules. This multipurpose power supply is installable in the universal backplane of RX3i PACSystems, and it occupies a single slot. It is used as a power supply module in the system, but it can also be combined with other similar power supplies, and it can be combined with a maximum of 3 additional modules.

The GE Fanuc RX3i PACSystems IC695PSD140 power supply module comes with LED indicators that provide status updates about the power supply. Every LED indicator is designed to show the operating status the power supply module. It has an input voltage ranging from 18 to 30 Volts DC, a nominal voltage rating of 24 Volts DC, and a maximum of 40 Watts of output power rating, with its 3 outputs included. This unit has no isolation, and it cannot be used with the GE Fanuc IC695PSA040 or IC695PSD040 power supplies under any circumstance. These units are not compatible with the IC695PSD140 power supply module and attempting to use them together can lead to equipment damage.
