GE FANUC INPUT MODULE IC694MDL655

GE Fanuc IC694MDL655 RX3i DC Voltage Input Module, 24V

brand:
GE Fanuc
item no:
IC694MDL655
payment:
T/T, Western Union, Credit Card
product origin:
USA
good stock:
6.0
shipping port:
Saudi Arabia
lead time:
1-3 Working Days
condition:
Brand New And Original
warranty:
12 Months
certificate:
COO
description:
RX3i DC Voltage Input Module 24V 32 Point
product type:
RX3i

Product Details
FAQs

GE Fanuc IC694MDL655 Input Module 32 Point 24V DC

Description

The IC694MDL655 is a 32-Point, 24 VDC, Positive/Negative Logic, Input module from the GE Fanuc RX3i Series. This module provides 32 discrete input points. The inputs are positive or negative logic inputs and will operate at levels up to 30V. See specifications for this unit on IC694MDL655's website page.

The number of channels in the IC694MDL655 may be single ended (1 to 16 channel) or differential (1 to 8 channel). The power requirement for this module is 112mA from 5V bus, and also it requires 41V from 24V DC supply to power the converters. The two LED indicators indicate the status of user power supply the module’ status. These two LEDs are MODULE OK, which gives the status regarding power-up, and POWER SUPPLY OK, which checks whether the supply is above the minimum required level. TheIC694MDL655 module is configured either using logic master programming software or via Handheld programming. If the user chooses to program the module via Handheld programming, he can only edit active channels, not active scanned channels. This module uses the %AI data table to record analog signals for the use of the programmable logic controller.
