GE Fanuc IS220PRTDHIA

General Electric IS220PRTDHIA Brand New

brand:
GE Fanuc
item no:
IS220PRTDHIA
payment:
T/T, Western Union, Credit Card
product origin:
USA
good stock:
9.0
shipping port:
Dammam, Saudi Arabia
lead time:
1-3 Days
condition:
Brand New And Original
warranty:
12 Months
certificate:
COO
description:
Control
product type:
Mark VIE

Product Details
FAQs

General Electric IS220PRTDHIA Card Brand New

Terminal Blocks

Signal flow begins with a sensor connected to a terminal block on an I/O module. Theterminal board mounts to the cabinet and is available in two basic types: T-type andS-type modules.

T-type modules typically fan the inputs to three separate I/O packs. They contain tworemovable 24-point, barrier-type terminal blocks. Each point can accept two 3.0 mm2(#12,AWG) wires with 300 V insulation per point and spade or ring-type lugs. Captiveclamps are also provided for terminating bare wires. Screw spacing is 9.53 mm (0.375 in)minimum, center-to-center. T-type modules are normally surface mounted, but may alsobe DIN-rail mounted.

A shield strip is provided next to each block, which is actually the left-hand side of themetal base where the module is mounted. Wide and narrow modules are arranged invertical columns of high and low-level wiring that can be accessed from top and/orbottom cable entrances. An example of a wide module is a module containing magneticrelays with fused circuits for solenoid drivers.
