GE Fanuc UR6TH Module

 100% New General Electric UR6TH Module

Description

The blue bands on the label show that MDL660 is a low-voltagemodule.This module can be installed in any I/O slot in an RX3i system. Itmust be used with an RX3i CPU (release 2.90 or later). It cannot beused with a Series 90-30 PLC CPU.Module MDL660 uses 48 input bits and 16 output bits to exchangepoint status and filter information with the RX3i CPU. The 24 VDC Positive/Negative Logic Input module, IC694MDL660,provides 32 discrete input points. The inputs are positive or negativelogic inputs and will operate at levels up to 30V.The inputs are arranged in four isolated groups of eight; each grouphas its own common. Isolation is provided between the four groupsof inputs, however each group of eight inputs is referenced to thesame user common connection.Module MDL660 provides seven selectable input filter times. Filtertimes can be set from the programmer using the module’s assignedoutput data references.This module can be used with either a Box-style (IC694TBB032) orSpring-style (IC694TBS032) front Terminal Block. The TerminalBlock is ordered separately.32 green LEDs indicate the ON/OFF status of points 1 through 32.The red/green TB LED is green when the module’s removableterminal block is locked in place. It is red when the terminal block isnot locked. The module also sends an Addition of Terminal Block orLoss of Terminal Block message to the RX3i CPU to report theterminal block status.
