High Quality Allen Bradley ControlLogix 1756-CN2R Module

Fast Delivery Allen Bradley 1756-CN2R Module  Best Price

Introduction

The Allen-Bradley 1756-IA32 is a ControlLogix Digital I/O Module.
This AC input module has a display where users can check its input and communication status, as well as the module health. It can be connected to a ControlLogix chassis and is configurable using the RSLogix 5000 software, where users can change the settings for the input filter times and change of state. This particular module has 32 inputs available, with 16 points available in each group. The removable terminal block housings or RTB, compatible with the 1756-IA32 are 1756-TBCH and 1756-TBS6H.
The continuous isolation voltage of this module is 250 V. Its voltage category is 120 V AC and 50/60 Hz, same with its input voltage. The module’s current draw at 24 V is 2mA and 165 mA at 5.1 V. The operating voltage ranges from 74 to 132 V AC and 47 to 63 Hz. 0.9 W is the 1756-IA32 module's total backplane power and the maximum inrush current is 390 mA. Input delay times, from screw to backplane, are present in this module from off to on hardware delay is 1.5 ms nominally or 10 ms maximum plus user-selectable filter time (1 ms or 2 ms), while from on to off, the hardware delay is 1 ms nominally or 8 ms maximum plus user-selectable filter time (9 ms or 18 ms). The maximum power dissipation is 6.1 W at 60 Degrees Celsius and thermal dissipation is 20.8 BTU/hour. On an off-state, the maximum voltage is 20 V and the maximum current is 2.5 mA. On the other hand, the on state’s current ranges from a minimum of 5 mA at 74 V AC to a maximum of 15 mA at 132 V AC.
The Allen-Bradley 1756-IA32 is a ControlLogix AC input module that is primarily used to interface input or signaling devices that provides AC input signals with range of 74-132VAC. This module is a high-density input module, featuring Thirty-Two (32) input channels, grouped in Two (2), having Sixteen (16) channels per group. This module has group to group isolation, allowing the module to function even if a group has malfunctioned. Additionally, it features an input to backplane isolation however, it has no isolation between input channels.
The 1756-IA32 is part of the ControlLogix Programmable Automation Controller (PAC) product family. Each channel of this input module has a fixed hardware delay such as 1.5 ms delay in the OFF to ON transition and 1 ms delay in the ON to OFF transition. A user configurable delay may also be set with filter time options of 1 ms or 2 ms for OFF to ON transition and 9 ms or 18 ms for the ON to OFF transition.

Allen Bradley Main Products:

1. SLC500:1747/1746 series
2.MicroLogix: 1761/1763/1762/1766/1764 series
3.CompactLogix: 1769/1768 series
4. The ControlLogix: 1756/1794/1760/1788 series
5. PLC-5:1771/1785 series
6.2711,2711P PanelView man-machine interface, touch screen, operation panel
7.22A,22B, 20 small frequency converter,150 soft starter
8. ProSoft: MVI69 / PS69 / MVI56 / MVI94 / MVI71 / MVI46/3150 9. ICS TRIPLEX: T8431 / T8461 / T3401 / T8310
