Honeywell 8C-PDIPA1 51454471-375 MODULE

HONEYWELL 8C-PDIPA1 51454471-375 MODULE  NEW

Description

Manufacturer : Honeywell

Product No. : 8C-PDIPA1 51454471-375

Product type :Digital Input Pulse Accumulation Module

Introduction

Adequate grounding is important for safety considerations and for reducing electromagnetic noise interference.All earth-ground connections must be permanent and provide a continuous low impedance path to earth groundfor induced noise currents and fault currents. Refer to the following guidelines when considering the groundingrequirements of your system:

For safe operations of your equipment, a high-integrity grounding system must be installed as part of thebuilding's wiring system.

-An equipment ground wire must be enclosed with the circuit conductors (phase and neutral wires).

-The size of the ground conductor must be the same as, or larger, than the circuit conductors supplying theequipment.

-The ground conductor must be securely bonded to the building-ground electrode.

-Grounding provisions must be in accordance with the NEC, CEC, and any other local codes.

-Ensure that the cabinet enclosure is connected to a protective earth ground using at least a #8 AWG solidcopper wire. There should be metal to metal contact between the grounding bus bar and the enclosure aswell as the channel. See the illustration below for more

Related Honeywell PLC modules

Honeywell RHMUX Remote FTA MC-GRMT01
Honeywell Digital Output 120/240 Vac Solid-State FTA MU-TDOA13 MC-TDOA13
Honeywell Digital Output 3-30 Vdc Solid-State FTA MU-TDOD13 MC-TDOD13
Honeywell Digital Output 3-30 Vdc Solid-State FTA MU-TDOD14 MC-TDOD14
Honeywell Digital Output 31-200 Vdc Solid-State MU-TDOD23 MC-TDOD23
Honeywell Digital Output 24 Vdc, 100 ma Nonisolated FTA MU-TDON12 MC-TDON12
Honeywell Digital Output 120 Vac/125 Vdc Relay FTA MU-TDOR12 MC-TDOR12
Honeywell Digital Output 240 Vac/125 Vdc Relay FTA MU-TDOR22 MC-TDOR22
Honeywell Digital Output 24 Vdc FTA MU-PDOY22 MU-TDOY22 MC-TDOY22
Honeywell Digital Output Relay FTA MU-PDOY22 MU-TDOY23 MC-TDOY23
