Honeywell MC-TDOR22 51309150-175 FTA Digital Output Module

Honeywell MC-TDOR22 51309150-175 Digital Output 240 Vac/125 Vdc Relay FTA 16 Outputs

brand:
Honeywell
item no:
Honeywell MC-TDOR22 51309150-175
payment:
TT Or Western Union
product origin:
USA
good stock:
20.0
shipping port:
Dammam
lead time:
1-3 Days
condition:
Original New And In Stock
warranty:
1 Year
certificate:
Co,Coo
product type:
Honeywell MC-TDOR22 51309150-175 FTA Card
system:
Honeywell TPS Process Manager I/O

Product Details
FAQs

New Honeywell MC-TDOR22 51309150-175 FTA Digital Output Module In Stock

Description

All connections to and from the process are made to Field Termination Assemblies (FTA). Compression-type termination blocks (that can accept wire sizes as large as 14 AWG or ~1.6 mm) are available for all FTAs. Screw-type termination's can also be provided for most FTAs as shown in Table 1 in the “Specifications” section. The FTAs are connected to the I/O processors by cables that can be up to 50 meters in length. Three sizes of FTAs are used as shown in this table. Twenty-four Vdc transmitter and digital inputs sense power connections are provided through the standard FTA cable

Honeywell Field Termination Assemblies FTA Modules

Coated Model Number	Uncoated Model Number	Description
MC-TDOR22	MU-TDOR22	Digital Output 240 Vac/125 Vdc Relay FTA (16 Outputs)
MC-TDID12	MU-TDID12	Digital Input 24 Vdc FTA (32 Inputs)
MC-TAOY22	MU-TAOY22	Analog Output 16 FTA (16 Outputs), w/StbyMan (use ONLY w/ MU-PAOY22)**
MC-TLPA02	MU-TLPA02	LLMUX, SDI, SI Power Adapter
MC-TAMR03	MU-TAMR04	Low Level Analog Input Multiplexer RTD FTA (16 Inputs)
MC-TAIH22	MU-TAIH22	Enhanced Power High Level /STI Analog Input FTA (16 Inputs) **
MC-TAIH02	MU-TAIH02	High Level Analog Input/STI FTA (16 Inputs)
MC-TAIH12	MU-TAIH12	High Level Analog Input/STI FTA for Redundancy (16 Inputs) **
MC-TAIH03	MU-TAIH03	High Level Analog Input FTA (16 Inputs) (CE Mark)
MC-TAIH13	MU-TAIH13	High Level Analog Input FTA for Redundancy (16 Inputs) (CE Mark) **
MC-TSTX03	MU-TSTX03	Smart Transmitter Interface FTA (16 Inputs) (CE Mark)
MC-TSTX13	MU-TSTX13	Smart Transmitter Interface FTA for Redundancy (16 Inputs) (CE Mark) **
MC-TAIH23	MU-TAIH23	Enhanced Power High Level Analog Input FTA (16 Inputs) (CE Mark)**
MC-TAIL02	MU-TAIL02	Low Level Analog Input FTA (8 Inputs)
MC-TAIL03	MU-TAIL03	Low Level Analog Input FTA (8 Inputs) (CE Mark)
MC-TAMT03	MU-TAMT04	Low Level Analog Input Multiplexer TC FTA (16 Inputs)
MC-TAMT13	MU-TAMT14	Low Level Analog Input Multiplexer TC FTA with Remote CJR (16 Inputs)
MC-GRPA01	MU-GRPA01	RHMUX GI/IS Power Adapter
MC-TRPA01	MU-TRPA01	RHMUX GI/NI Power Adapter
MC-TPIX12	MU-TPIX12	Pulse Input FTA (8 Inputs)
MC-TAOX02	MU-TAOX02	Analog Output FTA (8 Outputs)
MC-TAOX12	MU-TAOX12	Analog Output FTA for Redundancy (8 Outputs) **
MC-THAO11	MU-THAO11	Analog Output 16 FTA (16 Outputs), w/StbyMan and HART® connector (use ONLY w/ MU-PAOY22)**
MC-GHAO11	MU-GHAO11	GI/IS Analog Output 16 FTA (16 Outputs), w/o StbyMan, w/HART® connector (use ONLY w/ MU-PAOY22)**
MC-TDIA12	MU-TDIA12	Digital Input Isolated 120 Vac FTA (32 Inputs)
MC-TDIA22	MU-TDIA22	Digital Input Isolated 240 Vac FTA (32 Inputs)
MC-TDIY22	MU-TDIY22	Digital Input 24 Vdc FTA (32 Inputs) (use ONLY w/ MU-PDIY22)**
MC-TDOA13	MU-TDOA13	Digital Output 120/240 Vac Solid-State FTA (16 Outputs)
MC-TDOD13	MU-TDOD13	Digital Output 3-30 Vdc Solid-State FTA (16 Outputs)
MC-TDOD14	MU-TDOD14	Digital Output 3-30 Vdc Solid-State FTA (16 Outputs) (CE Mark)
MC-TDOD23	MU-TDOD23	Digital Output 31-200 Vdc Solid-State (16 Outputs)
MC-TDON12	MU-TDON12	Digital Output 24 Vdc, 100 ma Nonisolated FTA (16 Outputs)
MC-TDOR12	MU-TDOR12	Digital Output 120 Vac/125 Vdc Relay FTA (16 Outputs)
MC-TDOY22	MU-TDOY22	Digital Output 24 Vdc FTA (32 Outputs) (use ONLY w/ MU-PDOY22)**
MC-TDOY23	MU-TDOY23	Digital Output Relay FTA (16 Outputs) (use two w/ MU-PDOY22)**
