Honeywell MU-TDID72 51303928-100 Digital Input 24 FTA Module

Honeywell MU-TDID72 51303928-100 Digital Input 24 FTA Module

Honeywell MU-TDID72 51303928-100 Digital Input 24 Vdc DI FTA

  • brand:

    Honeywell
  • item no:

    Honeywell MU-TDID72 51303928-100
  • payment:

    TT Or Western Union
  • product origin:

    USA
  • good stock:

    30.0
  • shipping port:

    Dammam
  • lead time:

    1-3 Days
  • condition:

    Original New And In Stock
  • warranty:

    1 Year
  • certificate:

    Co,Coo
  • product type:

    Honeywell FTA Card MU-TDID72 51303928-100
  • system:

    Honeywell TPS Process Manager I/O

Honeywell MU-TDID72 51303928-100 Digital Input 24 FTA Module In Stock


Description

All connections to and from the process are made to Field Termination Assemblies (FTA). Compression-type termination blocks (that can accept wire sizes as large as 14 AWG or ~1.6 mm) are available for all FTAs. Screw-type termination's can also be provided for most FTAs as shown in Table 1 in the “Specifications” section. The FTAs are connected to the I/O processors by cables that can be up to 50 meters in length. Three sizes of FTAs are used as shown in this table. Twenty-four Vdc transmitter and digital inputs sense power connections are provided through the standard FTA cable


Honeywell Field Termination Assemblies FTA Modules

FTA Type Model Number Non-CE Compliant Part Number CE Compliant Part Number
HLAI MU-TAIH23 N/A 80369165-125
HLAI MU-TAIH53 N/A 51309138-225
STI MU-TSTX03 N/A 51309136-125
STI MU-TSTX13 N/A 51309138-125
STI MU-TSTX53 N/A 51309138-225
AO MU-TAOX02 51304476-100 51304476-125
AO MU-TAOX12 51304335-100 51304335-125
AO MU-TAOX52 51304335-200 51304335-225
AO MU-TAOY22 80366177-100 80366481-125
AO MU-TAOY23 80366177-200 N/A
AO MU-TAOY52 80364007-100 80366484-125
AO MU-TAOY53 80364007-200 N/A
24 Vdc DI MU-TDID12 51304441-100 51304441-125
24 Vdc DI MU-TDID52 51304441-200 51304441-225
24 Vdc DI MU-TDID72 51303928-100 N/A
24 Vdc DI MU-TDIY22 80366180-100 80366180-125
24 Vdc DI MU-TDIY62 80364010-100 80364010-125
120 Vac DI MU-TDIA12 51304439-100 51304439-125
120 Vac DI MU-TDIA52 51304439-200 51304439-225
120 Vac DI MU-TDIA72 51303930-100 N/A
240 Vac DI MU-TDIA22 51304431-100 51304431-125
240 Vac DI MU-TDIA62 51304431-200 51304431-225
24 Vdc Nonisolated DO MU-TDON12 51304446-100 N/A
24 Vdc Nonisolated DO MU-TDON52 51304446-200 N/A
24 Vdc Isolated DO MU-TDOY22 80366183-100 80366183-125
