Honeywell TC-IXR061 Experion RTD Input 6-Point Module

Brand New Honeywell TC-IXR061 Experion RTD Input 6-Point Module

brand:
Honeywell
item no:
Honeywell TC-IXR061
payment:
TT Or Western Union
product origin:
USA
good stock:
20.0
shipping port:
Dammam
lead time:
1-3 Days
condition:
Original New
warranty:
1 Year
certificate:
Co,Coo
product type:
TK-IXL061 Honeywell Experion Input Input Module
system:
Honeywell C200

Product Details
FAQs

Honeywell TC-IXR061 Experion RTD Input 6-Point I/O Module

Introduction

Honeywell's newest Universal I/O module, based on Universal Channel Technology, reduces or eliminates marshalling. More importantly, it allows immediate configuration without the need for additional hardware. Click on the Demo tab to view videos describing how this new technology can reduce marshalling and equipment needed.

Specification

Part No.	TC-IXR061
Number of Points	6 galvanically isolated channels
Nominal Input Voltage Ranges	-12 mV to +78 mV -12 mV to +30 mV (high resolution range)
Supported Thermocouple Types	B, E, J, K, R, S, T, N, C
Resolution	16 bits (1.4 V typical), 0.70 on high resolution range
Common Mode Rejection	120 dB @ 60 Hz, 100 dB @ 50 Hz
Module Update Rate for All Channels	50 milliseconds
Settling Time to 5% of Full Scale	Less than 80 milliseconds
Open Circuit Detection Open TC Detection Time	Upscale reading 5 seconds typical
Channel Bandwidth	0 to 15 Hz (-3 db)
Module Update Rate for All Channels	50 milliseconds
Spare CJR Thermistor Model Number	TC-CJRT01 (part no. 51109433-100)
Isolation Voltage Channel to channel User to system	100% tested at 2546 VDC for 1s 100% tested at 2546 VDC for 1s
Connection Terminal Blocks	TC-TBNH, 20-position terminal block

honeywell module

Honeywell Experion Products

Honeywell 51400646-100 Violet Drop Cable, 6 drops, 6-inch (152 mm) pitch, green label (cable B)
Honeywell 51202329-111 Violet Drop Cable, 6 drops, 6-inch (152 mm) pitch, yellow label (cable A)
Honeywell 51202329-110 Violet Extension Cable, 48-inches (1.2 m) long, yellow label (cable A)
Honeywell 51202329-734 Violet Extension Cable, 48-inches (1.2 m) long, green label (cable B)
Honeywell 51202329-735 Gray Header Cable, 3 drops, yellow label (cable A)
Honeywell 51202329-600 Gray Header Cable, 3 drops, green label (cable B)
Honeywell 51202329-601 Violet Header Cable, 3 drops, daisy-chain, yellow label (cable A)
Honeywell 51202329-614 Violet Header Cable, 3 drops, daisy-chain, green label (cable B)
Honeywell 51202329-615 Gray Drop Cable, 6 drops, 6-inch (152 mm) pitch, yellow label (cable A) I/O Link cable
Honeywell 51202329-100 Each I/O Link cable is available in an A version (marked yellow) and a B version
Honeywell Series C I/O Link cable parts HART Multiplexer
Honeywell Communication cables LLMux TC CE Compliant
Honeywell 51305890-175 MC-TAMT04
