Hot Selling And Original Allen Bradley 1746-OG16

Allen Bradley 1746-OG16 16 Channel SLC 500 Output Module

brand:
Allen Bradley
item no:
1746-OG16
payment:
T/T, Western Union, Credit Card
product origin:
USA
good stock:
16.0
shipping port:
Dammam
lead time:
1-3 Working Days
condition:
Brand New And Original
warranty:
12 Months
certificate:
COO
description:
16 Channel SLC 500 Output Module

Product Details
FAQs

lowest Price High Quality In Stock 1746-OG16

Description

The Allen-Bradley 1746-OG16 has voltage category of 5V DC TTL signal input (sinking). This module has Sixteen (16) TTL outputs and. The operating voltage of the 1746-OG16 is 4.5-5.5V DC with a maximum 50 mV peak-to-peak ripple. The 1746-OG16’s backplane current at 5V is 0.18A with backplane current at 24V is 0A. The Off-state voltage of this module is from 4.5-5.5 V DC. The maximum Off-state leakage current of this module is 0.1 mA. The continuous current per point is 24 mA. The 1746-OG16’s operating temperature is from -13-140 deg. Fahrenheit while the non-operating temperature is from -40-185 deg. Fahrenheit at 5-95% relative humidity without condensation. The operating vibration of this module is 2g at 10-500 Hz and 2.5 g at 57-2000 Hz while the operating shock is 30g.

The Allen-Bradley 1746-OG16 is intended for industrial environments with a pollution level no higher than Pollution 2 (as defined in EN / IEC0664-1). The enclosure should be accessible only by the included appliance. Do not disconnect equipment unless power has been removed and if the area is known to be dangerous because an electric arc will be created.

This output module, similar to the input module, has an inverted logic. To properly operate a TTL module, a NOT instruction is needed to be negated the naturall
