ICS Triplex T8120 Module

Rockwell Ics Triplex T8120 Brand New

Product Features:

- Allows easy access for external systems to communicate with a Trusted TMR Processor.

-Easy installation (connects directly to the rear of the Controller Chassis).

-Two RS422/485 configurable 2 or 4 wire connections.

- One RS422/485 2 wire connection.

- Fault/fail connections for Active and Standby Processors.

-Processor diagnostics connection.

-PSU shutdown monitor connections.

- Option for connecting IRIG-B122 and IRIG-B002 time synchronisation signals.

- Option to enable MODBUS Master on the Trusted Communications Interface.

Product Overview

This document provides general information for the Trusted® Processor Interface Adapter T812X.The Adapter provides easy access to the communications ports of the Trusted Triple ModularRedundant (TMR) Processor (T8110B & T8111) in the Controller Chassis for the Distributed ControlSystem (DCS) and other links. The unit is also used to enable a number of extended facilitiesavailable on the Trusted TMR Processor including facilities for the reception of IRIG-B timesynchronisation signals, enabling the use of Dual (‘enhanced’) Peer to Peer and enabling theTrusted System to become MODBUS Master.It is not intended that the information in this publication covers every possible detail about theconstruction, operation, or maintenance of a control system installation. You should also refer toyour own local (or supplied) system safety manual, installation and operator/maintenance manuals
