ICS TRIPLEX T8231 Module

Rockwell ICS Triplex T8231 Power Pack 24VDC

Product Overview

The Trusted® Power System is a high density flexible power supply designed to convert main linevoltages of either 110 Vac or 240 Vac. Outputs are either 24 Vdc for Trusted product or 28 Vdcadjustable field power.

The Trusted Power System consists of a 1U Power Shelf with mechanical support, containing up tothree 750 W Power Packs. The Power Packs load share in configurations using one or more PowerShelves. Each Power Pack has an individual supply connection via a mechanically retained IEC 60320type connector. Each Power Shelf can supply 2250 W of power or 1500 W with n+1 redundancyfrom a single source. Multiple units can be connected for further capacity or redundancyrequirements.

Diagnostic information of Power Pack status is provided via the Power Port, which connects to therear of the Power Shelf. This device monitors input and output conditions and reports out of rangefaults and over-temperature/fan failure using relay contacts. The Power Port also allows connectionof the optional rack mounted Power Controller for live configuration of output voltage and current,monitoring up to 12 Power Packs in 4 Power Shelves.

Features:

-Redundant and n+1 configurations.

-Hot replaceable Power Packs.

-Current sharing.

-Current limiting.

-Power factor correction.

-Diagnostic contacts.

-Configurable output voltage.

-Input/output fail diagnostics per Power Pack.
