ICS TRIPLEX T8431 Module

Rockwell Allen Bradley Ics Triplex T8431 40 channel

Product Overview

The Trusted® TMR 24 Vdc Analogue Input Module interfaces to 40 sourcing field input devices,acting as a current sink for all these devices. Comprehensive diagnostic tests are performed on eachinput channel. Fault tolerance is achieved through a Triple Modular Redundant (TMR) architecturewithin the Module for each of the 40 input channels.Using the built-in line-monitoring feature, the Module can detect open and shorted field cables.Line monitoring functions are independently configured for each input channel.The Module provides on-board Sequence of Events (SOE) reporting with a resolution of 1 ms. Achange of state triggers an SOE entry. States are determined by voltage thresholds that can beconfigured on a per channel basis. When the field voltage and field return are connected to theauxiliary input channels of the Module, thresholds can be specified as a ratio of the field supplyvoltage

Features:

-40 Triple Modular Redundant (TMR) input channels per Module.

- Comprehensive, automatic diagnostics and self-test

- Selectable line monitoring per channel to detect open circuit and short circuit field wiringfaults.

-2500 V impulse withstand opto/galvanic isolation barrier

-On-board Sequence of Events (SOE) reporting with 1 ms resolution

-Module can be hot-replaced on-line using dedicated Companion (adjacent) Slot or SmartSlot(one spare slot for many Modules) configurations.

-Front Panel input status Light Emitting Diodes (LEDs) for each channel indicate input statusand field wiring faults.
