ICS TRIPLEX T8461C Module

Rockwell ICS Triplex T8461C 24/48V dc Digital Output-40 channel

Product Overview

The Trusted® TMR 24 Vdc Digital Output Module interfaces to 40 field devices. TriplicatedT8461C diagnostic tests are performed throughout the Module including measurements for current,T8461C andvoltage on each portion of the voted output channel. Tests are also performed T8461Cfor stuck on andstuck off failures. Fault tolerance is achieved through a Triple Modular Redundant (TMR)architecture within the Module for each of the 40 output channels.Automatic line monitoring of the field device is provided. This feature enables the Module to detectboth open and short circuit failures in field wiring T8461Cand load devices.The Module provides on-board Sequence of Events (SOE) reporting with a resolution of 1 ms. Anoutput change of state triggers an SOE entry. Output states are automatically determined byvoltage and current measurements on-board the Module.This Module is not approved for direct connection to hazardous areas and should be used inconjunction with Intrinsic Safety Barrier devices.

Features:

- Triple Modular Redundant (TMR), fault tolerant (3-2-0) operation.

-Hardware Implemented Fault Tolerant (HIFT) architecture.

-Dedicated hardware and software test regimes which provide very fast fault recognition andresponse times.

-Automatic fault handling without nuisance alarming.

-Time-stamped fault historian.

-Hot replacement (no need to re-load programs).

- Full suite of IEC 61131-3 programming languages.

- Front panel indicators that show module health and status.

-Front panel RS232 serial diagnostics port for system monitoring, configuration andprogramming.
