New GE Fanuc IC200MDL740D Module

GE Fanuc IC200MDL740D Module 12 Months Warranty

Description

Communication between the controller and the I/O packs is performed with theinternal IONet. This is a 100 MB Ethernet network available in non-redundant, dualredundant, and triple redundant configurations. Ethernet Global Data (EGD) andother protocols are used for communication. EGD is based on the UDP/IP standard(RFC 768). EGD packets are broadcast at the system frame rate from the controllerto the I/O packs, which respond with input data.IONet conforms to the IEEE 802.3 standard. It is supplied as 100BaseTx and100BaseFx (fiber) for greater distances, noise rejection, lightning immunity, andground immunity. A star topology is used with the controller on one end, a networkswitch in the middle, and I/O packs at the end. The operator interface is commonly referred to as the Human-Machine Interface(HMI). It is a computer with a Microsoft® Windows-based operating system,client/server capability, a CIMPLICITY® graphics display system, and softwaremaintenance tools (ToolboxST). It can be applied as:• Primary operator station for one unit or the entire plant• Maintenance station gateway• Engineers station• Gateway for communicationsAll local and remote data inthe Mark VIe is accessible forscreens with high-resolutiontime tags for alarms andevents.The HMI can be re-initialized or replaced with the process running with no impacton the control system. It communicates with the main processor board in the MarkVIe controller(s) through the control network Unit Data Highway (UDH) and tothird-party control and monitoring systems through the information network PlantData Highway (PDH).
