Prosoft MVI56-ADM MODULE

Prosoft MVI56-ADM MODULE

Prosoft MVI56-ADM Module New In Box

  • brand:

    Other Product
  • item no:

    MVI56-ADM
  • payment:

    T/T, Western Union, Credit Card
  • product origin:

    USA
  • good stock:

    8.0
  • shipping port:

    Dammam
  • lead time:

    1-3 Working Days
  • condition:

    Brand New And Original
  • warranty:

    12 Months
  • certificate:

    COO

100% Brand New Original Inverter PLC MVI56-ADM


Product Descrition

The MVI56-ADM module features a debugging/configuration port, CFG port, serial ports P1/P2, and application specific ports (PRT1 and PRT2). The cables used for connecting the module must be 9 meters long for each port and there must be a 6 feet long RS-232 cable for configuration. Besides that, these modules include LED indicators for the status of the module, the status of the backplane transfer, the serial port activity, and the status of the application. The module is compatible with a single-slot 1756 backplane. This module operates in a temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) and within relative humidity levels of 5 to 95%. The storage temperature range of the module is between -40 and 85 degrees Celsius (-40 and 185 degrees Fahrenheit) and it can withstand a shock of 30 G when in operation and one of 50 G when not operating. Besides that, the module can tolerate a vibration of 5 G at a 10 to 150 Hertz frequency. The MVI56-ADM module is built to meet all of the requirements from the ATEX directive, CE, GOST-R, C/UL Class 1, the Korean KC registration, and several other relevant standards and certifications.
