Rockwell Allen Bradley 1762-OW16 Module New

Allen Bradley 1762-OW16 Module 12 Months Warranty

Introduction

The 1747 Port Splitters let a single RS-232/DF1 full-duplex communication port on acontroller split into two separate ports for simultaneous connection with two externaldevices. The Port Splitter supports the following: SLC 500, PLC-5, MicroLogix,ControlLogix, CompactLogix, and FlexLogix controllers.The Port Splitter has three ports for Controller, Network and Programmer/HMIconnections. It also has a connection for a +24V external power source and status LEDs.

• The Controller port connects to the RS-232/DF1 full-duplex port of a controller.The port configuration is set at DF1 full-duplex, 8 bits, no parity, 1 stop bit andCRC checksum on powerup. The port automatically sets the baud rate to 19.2 Kor 38.4 K baud taking advantage of the controller's maximum baud rate and canalso match the controller's CRC or BCC checksum.

• The Network port on the 1747-DPS1 connects to a 1761-NET-AIC,1761-NET-DNI or 1761-NET-ENI module and receives any messages initiatedfrom the controller. The network port can source power from the port splitter'sexternal power supply to one of the above modules if a 1761-CBL-AM00 or1761-CBL-HM02 cable is used.

• The Network port on the 1747-DPS2 provides similar functionality, but can beconfigured for communications with DH-485, DF1 half-duplex (master or slave),DF1 full-duplex, and DF1 radio modem networks. The port is programmed forDH-485 communication at the factory.

• The 1747-DPS2 port splitter has fully-isolated communication ports. Therefore,no external isolation is required.

• The Prog/HMI port connects to a programming station or HMI device(PanelView Standard, PanelView Plus, VersaView CE) for respond onlyoperations.

The serial configuration for the Network and Programmer/HMI ports on the1747-DPS1 port splitter must be set to DF1 full-duplex, 8 bits, no parity, 1 stop bit, 19.2K baud and CRC checksum.The Network port on the 1747-DPS2 port splitter can be configured forwonderduplex,and DF1 radio modem networks.
