ABB AO845A 3BSE045584R1 S/R HART Analog Output Module

ABB 3BSE045584R1 AO845AS800 I/O Analog Output S/R HART 8ch Module

The AO845A/AO845 Analog Output Module for single or redundant applications has 8 unipolar analog outputchannels. The module performs self-diagnosticcyclically.The module has HART pass-through functionality. Only point to pointcommunication is supported. The output filter must be enabled on channels used forHART communication.Five different types of MTUs can be used for single applications. The TU830/TU833 Extended MTU and the TU810 (or TU814) Compact MTU enables wireconnection to the devices without additional terminals. The TU812 Compact MTUhas a D-Sub 25 pin (male) connector for connection to the process.For redundant applications there are three types of MTUs, TU842/TU852 formounting on a horizontal DIN rail and TU843 for mounting on a vertical DIN rail.Shielded field cables for process connections are required if HART is used.

AO845A is in S800 I/O family. S800 I/O with Fieldbus Communication Interface CI801 and I/O ModulesMounted on Compact Type of Termination Units.The S800 I/O is distributed as modular I/O that communicates with numerouscontrollers over Advant Fieldbus 100 (AF100), PROFIBUS-DP, or directly.The S800 I/O provides easy installation of the I/O modules and process cabling.It is highly modularized and flexible so that I/O modules can be combined to suitmany applications. The S800 I/O can be mounted in many configurations to fit mostrequirements
