ABB IMDSI14 Digital Input Module

ABB IMDSI14 Digital Input Module NEW

brand:
ABB
item no:
IMDSI14
payment:
T/T, Western Union, Credit Card
product origin:
Sweden
good stock:
10.0
shipping port:
Saudi Arabia
lead time:
1-3 Days
condition:
Brand New And Original
warranty:
1 Year
certificate:
COO
description:
48 VDC Digital Input Module
product type:
Bailey INFI 90

Product Details
FAQs

ABB IMDSI14 48 VDC Digital Input Module

Missing I/O Module Error

A missing I/O module error (no FEC response or wrong type)occurs when the IMFEC1 address (set by dipswitch S1 on themodule) does not match the I/O module address in the controlmodule configuration (function code 132). This error appearsin the status bytes of the control module (bytes three throughfive). A missing I/O module error sets byte three equal to 03and bytes four and five equal to the block number of the missing I/O module.

A missing I/O module error also occurs if theI/O module and control module do not share the same I/Oexpander bus. To correct a missing I/O module error:1. Remove the module and check the setting of addressswitch S1. It should match the I/O module address set in function code 132 in the control module configuration. If the I/Omodule addresses match, go to Step 2. If the I/O moduleaddresses do not match, correct the I/O module addressingerror.
