Allen Bradley 1762-OA8 Output Module

Allen-Bradley 1762-OA8 MicroLogix Output Module

brand:
Allen Bradley
item no:
1762-OA8
payment:
T/T, Western Union, Credit Card
product origin:
USA
good stock:
6.0
shipping port:
Dammam
lead time:
1-3 Working Days
condition:
Brand New And Original
warranty:
12 Months
certificate:
COO
description:
MicroLogix Output Module
product type:
MicroLogix

Product Details
FAQs

Allen Bradley 1762-OA8 Micrologix 1200 Output Module

Description

The Allen-Bradley 1762-OA8 is a solid-state output module. Its non-operating temperature varies from -40 to 185 degrees Fahrenheit while its operating temperature varies from 32 to 131 degrees Fahrenheit. This module also complies with the NEMA ICS 2-230, EN50081-2 Class A, IEC1000-4-2, and the IEC1000-4-3 standards. The 1762-OA8 operates on 85 to 256 Volts AC at 47 to 63 Hertz. This module has 8 outputs. Its maximum bus current is 115 mA at 5 Volts DC and its maximum heat dissipation is 2.9 W. The maximum voltage drop of the 1762-OA8 is 1.5 Volts at 0.5 Amps while the minimum on-state current of this module is 10 mA.

The 1762-0A8 must be well-grounded on a proper mounting surface, like a metal panel. Refer to Allen-Bradley’s wiring and grounding guidelines for more information. Ensure that the module is free of all metal fragments before operation because these fragments could cause damage when the power is applied. Make sure to keep the finger-safe cover in place when wiring the terminal block. Once removed, the cover cannot be put back on the module because the wires’ position will prevent it. The 1762-0A8 is compatible with MicroLogix 1100, MicroLogix 1200, and MicroLogix 1400 systems.
