ALLEN BRADLEY 2711C-T3M NEW

Allen Bradley Panelview C300 2711C-T3M Touchscreen

Description

The 2711C-T3M is an Allen-Bradley PanelView Component 300 HMI terminal. The 2711C-T3M is a Monochrome transflective FSTN passive matrix terminal that can interface with a range of controllers including the Allen-Bradley Micro800 and MicroLogix families. It provides visualization solutions and variable controls for low-end applications that use Ethernet or serial communications. The 2711C-T3M operator interface comes with a 3-inch display which is a mix of a touchscreen interface and numeric keys. It has an embedded configuration environment that is accessible through a web browser using an Ethernet connection.

This operator terminal may be easily mounted via the provided mounting clamps and quick lever clamps for fast and easy installation. The 2711C-T3M PanelView component C300 terminal’s has an enclosure rating of NEMA/UL Type 4X (indoor) 12, 13, and IEC IP54, IP65 enclosed and it is cULus listed, CE marked, and C-Tick certified.

The 2711C-T3M has a power consumption of 5 Watts maximum and input voltage of 24 Volts DC normal. The heat dissipation is 16BTU/hour with an operating temperature range of (32 to 122 degrees Fahrenheit). It is possible to reset the terminal without disconnecting and reapplying power. Moreover, the users can apply login credentials and view system information through side tabs.

The 2711C-T3M weighs less than 0.43 pounds and a display size of 3 inches or 80 x 116 x 57 millimeters (3.15 x 4.54 x 2.23 inches), the PanelView Component C300 Terminal has a backlight time of more than 50,000 hours. The 2711C-T3M has also the option to select the storage location of the application from USB storage, SD card or PC. 2711C-T3M has a monochrome transflective FSTN passive matrix display. The display screen size is 3 inches. The 2711C-T3M backlight is a white LED indicator. On the power ports and communication ports of the 2711C-T3M, the wiring category is 1. Operators can input information into the 2711C-T3M through a keypad or touchscreen. The memory card of the 2711C-T3M is a USB port. The programming port is also a USB device port.

About us

Our office is located in Dammam, Saudi Arabia, cooperate with original manufacturer directly; Equipped with a professional sales team, own engineer for technical support and good after-sale service;Large inventory with original product quality for fast delivery. These help us become as a strong supporter of our clients: providing solution for the end-user, and also ensuring profits for the re-seller.FAQ:
