Honeywell MC-TDOY22 51204160-175 Digital Output FTA Card

Honeywell MC-TAOY22 51204172-175 Digital Output 24 Vdc FTA (32 Outputs) (use ONLY w/ MU-PDOY22)

brand:
Honeywell
item no:
Honeywell MC-TAOY22 51204172-175
payment:
TT Or Western Union
product origin:
USA
good stock:
20.0
shipping port:
Dammam
lead time:
1-3 Days
condition:
Original New And In Stock
warranty:
1 Year
certificate:
Co,Coo
product type:
Honeywell MC-TAOY22 51204172-175 FTA Module
system:
Honeywell TPS Process Manager I/O

Product Details
FAQs

Original New Honeywell MC-TDOY22 51204160-175 Digital Output FTA Module

Description

All connections to and from the process are made to Field Termination Assemblies (FTAs). Compression-type termination blocks (that can accept wire sizes as large as 14 AWG or ~1.6 mm) are available for all FTAs. Screw-type termination's can also be provided for most FTAs as shown in Table 1 in the “Specifications” section. The FTAs are connected to the I/O processors by cables that can be up to 50 meters in length. Three sizes of FTAs are used as shown in this table. Twenty-four Vdc transmitter and digital inputs sense power connections are provided through the standard FTA cable

Honeywell Field Termination Assemblies FTA Modules

FTA Model Number	Description	CE Compliant Part Number	Non-CE Compliant Part Number
MC-TDOY22	24 Vdc Isolated Digital Output with compression term	80366183-175	80366183-150
MC-TDIY22	24 Vdc Digital Input with compression terminals	80366180-175	80366180-150
MC-TDIA62	240 Vac Digital Input with fixed-screw terminals	51304431-275	51304431-250
MC-TDID12	24 Vdc Digital Input with compression terminals	51304441-175	51304441-150
MC-TDID52	24 Vdc Digital Input with fixed-screw terminals	51304441-275	51304441-250
MC-TDID72	24 Vdc Digital Input with removable-screw terminals	N/A	51303928-150
MC-TDIY62	24 Vdc Digital Input with fixed-screw terminals	80366180-275	80366180-250
MC-TDOA13	120/240 Vac Solid-State Digital Output w/comp term	51304648-175	51304648-150
MC-TDOA53	120/240 Vac Solid-State Digital Output w/screw term	51304648-275	51304648-250
MC-TDOD13	3-30 Vdc Digital Output with compression terminals	N/A	51304650-150
MC-TDOD14	3-30 Vdc Digital Output with compression terminals	51309153-175	N/A
MC-TDOD22	31-200 Vdc Digital Output with compression terminals	N/A	51304428-150
MC-TDOD23	31-200 Vdc Digital Output with compression terminals	51309154-175	N/A
MC-TDOD53	3-30 Vdc Digital Output with screw terminals	N/A	51304650-250
MC-TDOD54	3-30 Vdc Digital Output with screw terminals	51309153-275	N/A
MC-TDOD62	31-200 Vdc Digital Output with screw terminals	N/A	51304428-250
MC-TDOD63	31-200 Vdc Digital Output with screw terminals	51309154-275	N/A
MC-TDON12	24 Vdc Nonisolated Digital Output with comp term	N/A	51304446-150
MC-TDON52	24 Vdc Nonisolated Digital Output with screw term	N/A	51304446-250
MC-TDOY62	24 Vdc Isolated Digital Output with screw terminals	80364013-175	80364013-150
MC-TDOR12	120 Vac/125 Vdc Relay Digital Output with comp term	51309148-175	51304443-150
MC-TDOR52	120 Vac/125 Vdc Relay Digital Output with screw term	51309148-275	51304443-250
MC-TDOR22	240 Vac/125 Vdc Relay Digital Output with comp term	51309150-175	51304427-150
MC-TDOR62	240 Vac/125 Vdc Relay Digital Output with screw term	51309150-275	51304427-250
