Honeywell MU-TDID12 53104441-100 Digital Input FTA Board

Honeywell MU-TDID12 53104441-100 Digital Input 24 Vdc FTA (32 Inputs) 53104441-100 51304441-125

brand:
Honeywell
item no:
Honeywell MU-TDID12 53104441-100
payment:
TT Or Western Union
product origin:
USA
good stock:
30.0
shipping port:
Dammam
lead time:
1-3 Days
condition:
Original New And In Stock
warranty:
1 Year
certificate:
Co,Coo
product type:
Honeywell FTA Card MU-TDID12 53104441-100
system:
Honeywell TPS Process Manager I/O

Product Details
FAQs

Honeywell MU-TDID12 53104441-100 DI 24 Vdc FTA In Stock

Description

All connections to and from the process are made to Field Termination Assemblies (FTA). Compression-type termination blocks (that can accept wire sizes as large as 14 AWG or ~1.6 mm) are available for all FTAs. Screw-type termination's can also be provided for most FTAs as shown in Table 1 in the “Specifications” section. The FTAs are connected to the I/O processors by cables that can be up to 50 meters in length. Three sizes of FTAs are used as shown in this table. Twenty-four Vdc transmitter and digital inputs sense power connections are provided through the standard FTA cable

Honeywell Field Termination Assemblies FTA Modules

FTA Model Number	Non-CE Compliant Part Number	CE Compliant Part Number	FTA Type
MU-TAIH23	N/A	80369165-125	HLAI
MU-TAIH53	N/A	51309138-225	HLAI
MU-TSTX03	N/A	51309136-125	STI
MU-TSTX13	N/A	51309138-125	STI
MU-TSTX53	N/A	51309138-225	STI
MU-TAOX02	51304476-100	51304476-125	AO
MU-TAOX12	51304335-100	51304335-125	AO
MU-TAOX52	51304335-200	51304335-225	AO
MU-TAOY22	80366177-100	80366481-125	AO
MU-TAOY23	80366177-200	N/A	AO
MU-TAOY52	80364007-100	80366484-125	AO
MU-TAOY53	80364007-200	N/A	AO
MU-TDID12	51304441-100	51304441-125	24 Vdc DI
MU-TDID52	51304441-200	51304441-225	24 Vdc DI
MU-TDID72	51303928-100	N/A	24 Vdc DI
MU-TDIY22	80366180-100	80366180-125	24 Vdc DI
MU-TDIY62	80364010-100	80364010-125	24 Vdc DI
MU-TDIA12	51304439-100	51304439-125	120 Vac DI
MU-TDIA52	51304439-200	51304439-225	120 Vac DI
MU-TDIA72	51303930-100	N/A	120 Vac DI
MU-TDIA22	51304431-100	51304431-125	240 Vac DI
MU-TDIA62	51304431-200	51304431-225	240 Vac DI
MU-TDON12	51304446-100	N/A	24 Vdc Nonisolated DO
MU-TDON52	51304446-200	N/A	24 Vdc Nonisolated DO
MU-TDOY22	80366183-100	80366183-125	24 Vdc Isolated DO
