Invensys Triconex 3505E PLC Digital Input Module

Invensys Triconex 32-Point Digital Input Module 3505E

brand:
Invensys Triconex
item no:
Invensys Tricon 3505E
payment:
TT,Western Union
product origin:
USA
shipping port:
Dammam
lead time:
1-3 Working Days
condition:
Original New And In Stock
warranty:
1 Year
certificate:
Co,Coo
product type:
Digital Input Module
system:
Tricon Systems

Product Details
FAQs

Original new Invensys Triconex 3505E TMR Digital Input Module in Stock

Invensys Digital Input Module Introduction

Each TMR Digital Input (DI) module has three isolated input channels which independently process all data input to the module. A microprocessor on each channel scans each input point,compiles data, and transmits it to the Main Processors upon demand. Then input data is voted at the Main Proces-sors just prior toprocessing to ensure the highest integrity. All critical signal paths are 100 percent triplicated for guaranteed safety and maximum avail-ability. Each channel conditions signals independently and provides optical isolation between the field and the Tricon.

Models 3502E, 3503E, and 3505E can self-test to detect stuck-On conditions where the circuitry cannot tell whether a point has gone to the Off state. Since most safety systems are set up with a de-energize-to-trip capability, the ability to detect Off points is an impor-tant feature.

Invensys Digital Input Module Specifications

Model Number	Input Module 3501E/3501T	Input Module 3502E	Input Module 3503E	Input Module 3505E
Points	32, non-commoned,isolated	32, commoned in groups of 8	32, commoned in groups of 8	32, commoned in groups of 8
AC Range/DC Range	90-155 VAC/VDC	35-95 VAC/VDC	20-42.5 VAC/VDC	32, commoned in groups of 8
Frequency Range	DC or 47-63 Hz	DC or 47-63 Hz	DC or 47-63 Hz	n/a
Maximum Voltage	155 VAC/VDC	95 VAC/VDC	42.5 VAC/VDC	42.5 VDC
Nominal Turn-On	6-9 mA	6-9 mA	6-9 mA	3 mA to 5 mA
Input Delay OFF to ON/ON to OFF	< 8 ms/< 15 ms	< 8 ms/< 15 ms	< 8 ms/< 15 ms	< 8 ms/< 15 ms

Invensys Triconex Modules types

Processor Module:3006、3007、3008
Digital Input Module :3501E、3502E、3503E、3504E、3505E、3564

Analog Input Module :3700、3701、3703E、3704E

Pulse Input Module:3510、3511、3515

Thermocouple Input Module: 3706A

Digital Onput Module :3625、3601E、3603B、3603E、3604E、3607E、3664、3674, 3613E、3611、3614E、3615E、3617E,3624、3623

Analog Onput Module : 3805E

Communication Onput Module TCM: 4351B、4119、4119A、4329
