Invensys Triconex 8312 Power Modules In Tricon Systems

Foxboro Invensys Tricone 8312 Power Module in Stock

brand:
Invensys Triconex
item no:
Invensys Triconex 8312
payment:
TT,Western Union
product origin:
USA
shipping port:
Dammam
lead time:
1-3 Working Days
condition:
Original New And In Stock
warranty:
1 Year
certificate:
Co,Coo
product type:
Power Supply Module
system:
Tricon Systems

Product Details
FAQs

Invensys Triconex 8312 Power Modules in Tricon systems

Invensys Power Modules Introduction

Each Tricon chassis is equipped with two Power Modules—either one is fully capable of running the Tricon at full load and rated temperature. Each Power Module can be replaced online.The Power Modules, located on the left side of the chassis, convert line power
to DC power appropriate for all Tricon modules. Terminal strips for system grounding, incoming power and hard-wired alarms are located on the lower left corner of the backplane. Incoming power should be rated for a minimum of 240 watts per power supply.

Invensys Power Modules Specifications

Power Module Model	Tricon 8310	Tricon 8311	Tricon 8312
Chassis Type	Main/Expansion/RXM	Main/Expansion/RXM	Main/Expansion/RXM
Nominal Voltage	120 VAC/VDC	24 VDC	230 VAC
Input VAC @ 47-63 Hz	85–140	n/a	185–285
Input VDC	95–180	22–31	n/a
Fuse Rating and Type	5 amps, time-delay	15 amps, time-delay	2.5 amps, time-delay
Output Hold Time(nominal to 0 volts)	20 ms minimum	2.8 ms minimum	20 ms minimum
Diagnostic Indicators	PASS, FAULT, ALARM, TEMP,BAT LOW	PASS, FAULT, ALARM, TEMP,BAT LOW	PASS, FAULT, ALARM, TEMP,BAT LOW

Invensys Triconex Modules types

Processor Module:3006、3007、3008
Digital Input Module :3501E、3502E、3503E、3504E、3505E、3564

Analog Input Module :3700、3701、3703E、3704E

Pulse Input Module:3510、3511、3515

Thermocouple Input Module: 3706A

Digital Onput Module :3625,3601E、3603B、3603E、3604E、3607E、 3664、3674, 3613E、3611、3614E、3615E、3617E,3624、3623

Analog Onput Module : 3805E

Communication Onput Module TCM: 4351B 4119 4119A 4329

Invensys Tricon power module
