10105/2/1 Honeywell Analog Input Module

HONEYWELL 10105/2/1 INPUT MODULE,ANALOG,36VDC,16 CHANNEL

Redundant IO configurations

Redundant IO configurations can be used in Safety Manager with a redundantController.10105/2/1 In this fully redundant configuration, each Control Processor has itsown IO system to which it has exclusive access.Each Control Processor reads its own input interfaces once every program cycle.10105/2/1 After input matching, both Control Processors execute the user-defined controlprogram and update their output interfaces according to the results. Beforesetting,10105/2/1 the Control Processors compare the calculated output results to ensureidentical operation.Redundant IO configurations are typically used for safety functions that requireoptimal availability.10105/2/1 With Safety Manager R120, also Analog Outputs can be used in a redundanttopology.

Available interfaces are:

In the Safety Manager Guides an approved basic Fire and Gas Safety applicationis included. This application provides a Fire and Gas Safety Solution that caneasily be integrated into Honeywell’s Experion™ PKS,10105/2/1Honeywell’s TotalPlantSolution (TPS) system or into Honeywell’s PlantScape system. The basicapplication can be developed and adjusted easily to design a project specific Fireand Gas Safety Solution.

The integrated layer of the F&G solution within Experion, TPS or PlantScapecontains the integrated alarm listing and safety historian functionality thatrecords all detected alarms, all actions initiated by the F&G Safety system andall actions executed by this system or connected integrated sub-systems. 10105/2/1Thislayer also shows the actual situation of the F&G application by using overallplant displays and various detailed area displays that contain locations andactual status of all connected F&G field detectors.
